B181 6 Inch CBN Grinding Wheels Untuk Band Saw Mengasah W/M10/30
Product Details
| Nama: | Roda Gerinda CBN Dilapisi | Penggunaan: | Penggilingan untuk gergaji pita |
|---|---|---|---|
| Spesifikasi: | W/M, 6 Inci | Ukuran: | 6'' |
| Agen pengikat: | dilapisi listrik | Bahan: | Baja |
| Menyoroti |
B181 6 Inch CBN Grinding Wheels,M10 6 Inch CBN Grinding Wheels,B181 cbn wheel 6 inch |
||
Product Description
6 Inch CBN Grinding Wheels Untuk Band Saw Sharpening W/M10/30 B181
Keterangan:
Roda gerinda CBN yang dilapisi digunakan untuk mengasah gergaji pita paduan tinggi.
Roda gerinda CBN umumnya digunakan untuk memproses merek gergaji pita, antara lain:
Wood-Mizer, Timberwolf, Simonds, Kasco, Morse, Lenox, Dakin Flathers/Ripper 37 dan lainnya
Spesifikasi:
* 10/30 - profil roda gerinda universal yang paling banyak digunakan
* 29/9 - mempersiapkan gergaji pita dengan sempurna untuk memotong musim dingin, atau memotong Kayu keras
* 13/29 - profil roda yang mempersiapkan gergaji pita untuk pemotongan kayu lunak
* 4/32 - profil roda yang dapat menyiapkan gergaji pita untuk pemotongan kayu yang sangat beku dan sangat keras
* 7/34 profil roda CBN direkomendasikan untuk kayu keras
Menggambar:
Gambar roda gerinda CBN (roda galvanik) untuk mata gergaji pita
Ukuran:
| Diameter luar |
Diameter lubang bagian dalam: |
||
| inci |
mm |
inci |
mm |
| 5 |
127 |
1/2 |
12,7 |
| 6 |
150 |
25/32 |
20 |
| 8 |
203 |
1, 1 1/4 |
25,4, 32 |
|
Ukuran khusus dapat diproduksi sesuai dengan profil gergaji pita. |
|||
